Clinical Overview
The C‑CLEAR 2 is a top-tier, apochromatic optical dental microscope engineered by COXO for enhanced endodontic and microsurgical procedures. With precision multi-layer coated optics, 5-step magnification up to 20×, and high-intensity adjustable LED illumination, it enables superior visualization of fine intraoral structures with accurate color fidelity.
Key Benefits
- Apochromatic optics: exceptional chromatic correction ensures real tissue colors and sharp clarity.
- Five-level gear zoom: 3.2×, 5×, 8×, 12.8×, 20× magnification for flexible working distances and detailed inspection.
- High eye-point eyepieces: 12.5× wide-angle lenses with +7/−7 D diopter adjustment suit eyeglass wearers comfortably.
- Adjustable binocular tube: 0–180° tilt with 170 mm working distance, promoting ergonomic comfort.
- LED illumination: 30 000–65 000 lux brightness, CRI > 90%, with optional filters to control composite curing exposure.
- Robust support system: German gas-spring arm and silent casters ensure stable positioning and quiet operation.
Kit Contents
- 1 × C‑CLEAR 2 microscope head
- 12.5× wide-angle eyepieces with diopters
- 5-step gear zoom module
- Fixed-focus objective lens (250 mm) – optional 200–300 mm zoom lens
- LED illumination with adjustable brightness and filter options
- Double-handle 0–180° binocular tube
- Gas-spring articulated arm and mobile base with mute casters
- Optional camera integration (Sony/Canon external or built-in 4K)
Technical Specifications
- Optical system: fully apochromatic with multi-layer nano coatings.
- Magnification: 3.2× / 5× / 8× / 12.8× / 20× via mechanical zoom.
- Eyepiece: 12.5× WF, +7/−7 D diopter, high eye-point.
- Working distance: 200–415 mm (fixed 250 mm or optional zoom objective).
- Illumination: LED, 30 000–65 000 lux, CRI > 90%, multi-filter.
- Ergonomics: angled binocular tube, gas-spring arm, and mute casters.
- Camera options: supports external Sony/Canon cameras or built-in 4K system.
Indications
- Microsurgical endodontics and retreatments
- Precision operative procedures (e.g. fine caries removal, SLA)
- Implantology, periodontics, and restorative dentistry requiring high magnification
- Clinical training and documentation with optional camera capture
Instructions for Use
- Mount microscope on stable base or ceiling/floor stand; lock arm pivots.
- Adjust binocular tube angle and interpupillary distance to align with user.
- Focus at working distance using fixed or zoom objective.
- Select desired magnification and refine focus.
- Adjust LED brightness; engage filters when polymerizing composites.
- If attached, align camera output and adjust framing.
Summary
The C‑CLEAR 2 Deluxe microscope offers apochromatic clarity, versatile magnification, ergonomic handling, and clinical-grade illumination—all in a robust support system. It is ideally suited for high-precision dental diagnostics, microsurgery, and documentation workflows.
